【DIN】DN100德標橡膠膨脹節“DIN2501”

服務內容：【DIN】DN100德標橡膠膨脹節“DIN2501”

簡介：【DIN】DN100德標橡膠膨脹節“DIN2501” [DIN] DN100 German standard rubber expansion joint "din2501" 上海淞江減震器集團有限公司官方網站為您介紹：【DIN】DN100德標橡膠膨脹節“DIN2501”信息，淞江集團常......

【DIN】DN100德標橡膠膨脹節“DIN2501”
[DIN] DN100 German standard rubber expansion joint "din2501"

上海淞江減震器集團有限公司官方網站為您介紹：【DIN】DN100德標橡膠膨脹節“DIN2501”信息，淞江集團常年出口德標橡膠膨脹節，執行標準DIN2501 PN16，以下是DN100德標橡膠膨脹就介紹。
The official website of Shanghai Songjiang shock absorber Group Co., Ltd. introduces to you: [DIN] DN100 German standard rubber expansion joint "din2501" information. Songjiang group exports German standard rubber expansion joint all year round, and the executive standard is din2501 PN16. The following is the introduction of DN100 German standard rubber expansion joint.

一、DIN2501德標橡膠膨脹節實物拍照：

二、DIN2501德標橡膠膨脹節參數介紹：

名稱：德標橡膠膨脹節
型號：DN100
安裝長度：150mm
軸向壓縮：18mm
軸向伸長：10mm
軸向拉伸：10mm
橫向位移：12mm
偏轉角度：15°
標準：DIN 2501
壓力：PN16
法蘭：碳鋼（Q235）
介質：普通水、
質保：3年

橡膠材質：天然橡級

使用優點：減震、降噪、保護冷水機組的長期使用，降低維修成本。

生產廠家：上海淞江減震器集團有限公司

資質證書：合格證、質保書、檢驗報告、德國萊茵TUV認證、國家型式試驗報告、第三方性能檢測報告、含量成分檢測報告。

了解該產品更多型號參數表請點擊：【樣冊P43】德國標準橡膠膨脹節

Name: single ball standard rubber joint

Model: DN100

Installation length: 150mm

Axial compression: 18mm

Axial elongation: 10mm

Axial tension: 10mm

Lateral displacement: 12mm

Deflection angle: 15 degrees.

Standard: DIN 2501

Pressure: PN16

Flange: carbon steel (Q235)

Medium: ordinary water,

Warranty: 3 years

Rubber Material:

Advantages: shock absorption, noise reduction, protection of the long of chillers, and reduction of maintenance costs.

Manufacturer: Shanghai Songjiang shock absorber Group Co., Ltd.

Qualification Certificate: Qualification Certificate, Quality Guarantee, Inspection Report, TS Pressure Pipeline Production License of Rubber Joint Industry, National Type Test Report, Third Party Performance Test Report, Content Component Test Report.淞江集團橡膠膨脹節生產流程：原材料檢測-小料自動配料-大料自動配料-自動混煉-自動成筒-自動成型-自動硫化-質量檢測-實驗室檢測-交付客戶
Production process of rubber joint in Songjiang group：Raw Material Testing - Automatic Blending of Small Material - Automatic Blending of Large Material - Automatic Mixing - Automatic Forming - Automatic Sulfuration - Quality Testing - Laboratory Testing - Delivery to Customers

三、DIN2501德標橡膠膨脹節發貨現場：

四、DIN2501德標橡膠膨脹節工廠介紹：

相關鏈接：橡膠接頭工程案例
