DINCASE SHOW

【DIN】DN80德國標準橡膠膨脹節“DIN2501”

服務內容:【DIN】DN80德國標準橡膠膨脹節“DIN2501”

簡介:DN80德國標準橡膠膨脹節“DIN2501工廠” DN80 German standard rubber expansion joint "din2501 factory" 上海淞江減震器集團有限公司官方網站為您介紹:DN80德國標準橡膠膨脹節“DIN2501工廠”信息,淞江集團......

DN80德國標準橡膠膨脹節“DIN2501工廠”
DN80 German standard rubber expansion joint "din2501 factory"

上海淞江減震器集團有限公司官方網站為您介紹:DN80德國標準橡膠膨脹節“DIN2501工廠”信息,淞江集團為眾多企業提供德國DIN2501標準橡膠膨脹節,法蘭全部采用碳鋼材質,橡膠采用天然橡膠,以下是詳細介紹。
The official website of Shanghai Songjiang shock absorber Group Co., Ltd. introduces to you the information of DN80 German standard rubber expansion joint "din2501 factory". Songjiang group provides many enterprises with German din2501 standard rubber expansion joint. All flanges are made of carbon steel and rubber is made of natural rubber. The following is a detailed introduction.

一、DIN2501德國標準橡膠膨脹節實物拍照:
【DIN】DN80德國標準橡膠膨脹節“DIN2501”
【DIN】DN80德國標準橡膠膨脹節“DIN2501”
【DIN】DN80德國標準橡膠膨脹節“DIN2501”

二、DIN2501德國標準橡膠膨脹節參數介紹:

名稱:德國標準橡膠膨脹節
型號:DN80
安裝長度:135mm
軸向壓縮:12mm
軸向拉伸:6mm
橫向位移:10mm
偏轉角度:15°
標準:DIN 2501
壓力:PN16
法蘭:碳鋼(Q235)
介質:普通水、
質保:3年

橡膠材質:天然橡膠
使用優點:減震、降噪、保護冷水機組的長期使用,降低維修成本。
生產廠家:上海淞江減震器集團有限公司
資質證書:合格證、質保書、檢驗報告、德國萊茵TUV認證、國家型式試驗報告、第三方性能檢測報告、含量成分檢測報告。

了解該產品更多型號參數表請點擊:【樣冊P43】德國標準橡膠膨脹節

Name: single ball standard rubber joint
Model: DN80
Installation length: 135mm
Axial compression: 12mm
Axial tension: 6mm
Lateral displacement: 10mm
Deflection angle: 15 degrees.
Standard: DIN 2501
Pressure: PN16
Flange: carbon steel (Q235)
Medium: ordinary water,
Warranty: 3 years
Rubber Material:
Advantages: shock absorption, noise reduction, protection of the long of chillers, and reduction of maintenance costs.
Manufacturer: Shanghai Songjiang shock absorber Group Co., Ltd.
Qualification Certificate: Qualification Certificate, Quality Guarantee, Inspection Report, TS Pressure Pipeline Production License of Rubber Joint Industry, National Type Test Report, Third Party Performance Test Report, Content Component Test Report.

三、DIN2501德國標準橡膠膨脹節發貨現場:

【DIN】DN80德國標準橡膠膨脹節“DIN2501”

四、DIN2501德國標準橡膠膨脹節工廠介紹:

【DIN】DN80德國標準橡膠膨脹節“DIN2501”
【DIN】DN80德國標準橡膠膨脹節“DIN2501”
【DIN】DN80德國標準橡膠膨脹節“DIN2501”
